Additional Information about IPC3618SR3-ADF28KM-G | Uniview 8MP Fixed Lens Dome Camera

FAQs
What resolution does the Uniview IPC3618SR3-ADF28KM-G offer?

The IPC3618SR3-ADF28KM-G provides ultra-high-definition 8MP resolution (3840 × 2160), delivering sharp and detailed video capture suitable for various security applications.

What lens options are available for the IPC3618SR3-ADF28KM-G?

This camera offers a fixed lens choice: a 2.8mm lens for a wider field of view.

How effective is the night vision on the Uniview IPC3618SR3-ADF28KM-G?

The camera features Smart IR technology that allows for clear night vision up to 30 meters (98 feet), ensuring reliable performance even in complete darkness.

Does the IPC3618SR3-ADF28KM-G support smart detection features?

Yes, it includes a variety of smart detection capabilities such as motion detection, intrusion detection, cross-line detection, and tampering alarms, enhancing real-time threat awareness.

How weatherproof and vandal-resistant is the Uniview IPC3618SR3-ADF28KM-G?

The camera is designed with IP67-rated weatherproofing for outdoor use and IK10-rated vandal resistance, ensuring durability against harsh conditions and physical impacts.

What video compression technologies are supported by the IPC3618SR3-ADF28KM-G?

It supports Ultra 265, H.265, H.264, and MJPEG video compression formats, optimizing storage efficiency and network bandwidth usage.

Does the IPC3618SR3-ADF28KM-G support remote viewing?

Yes, the camera is compatible with Uniview’s EZView mobile application and supports ONVIF standards for seamless integration with various NVR systems and remote monitoring platforms.

How does Wide Dynamic Range (WDR) enhance the performance of the IPC3618SR3-ADF28KM-G?

The 120dB true WDR feature ensures balanced image exposure in scenes with strong lighting contrasts, making it easier to capture clear details in both bright and dark areas of the image.

What power options are available for the IPC3618SR3-ADF28KM-G?

The camera supports 12V DC ±25% power input as well as Power over Ethernet (PoE), which simplifies installation by allowing power and data to run through a single cable.

Does the IPC3618SR3-ADF28KM-G offer edge storage capabilities?

Yes, the camera supports microSD card storage of up to 256GB, providing convenient local video recording directly on the device.

Tech Spec

Image Sensor: 1/2.7" Progressive Scan CMOS

Maximum Resolution: 3840 × 2160 (8MP) Ultra HD resolution

Lens Options: 2.8 mm or 4.0 mm fixed lens

Night Vision (IR Distance): Up to 30 meters (98 feet) IR range for clear low-light performance

Video Compression: Ultra 265, H.265, H.264, MJPEG

Smart Detection Features:

  • Human body detection
  • Motion detection
  • Tampering alarm
  • Intrusion detection
  • Cross line detection

Audio Capability: Built-in microphone, G.711 audio compression

Weatherproof Rating: IP67, suitable for indoor and outdoor use

Vandal Resistance: IK10 impact-resistant housing

Wide Dynamic Range (WDR): 120 dB True WDR for clear images in challenging lighting

Edge Storage: Supports Micro SD card up to 256GB, ANR (Automatic Network Replenishment), NAS (NFS)

Power Supply: 12V DC ±25%, PoE (IEEE 802.3af)

Network Compatibility: ONVIF (Profiles S, G, T), API, SDK integration support

Operating Conditions: -30°C to +60°C (-22°F to +140°F), humidity ≤95% (non-condensing)

Dimensions: 111 × 82 mm (4.4” × 3.2”)
Weight: Approximately 0.52 kg (1.15 lb)
